Warthog Armoured All Terrain Repair Recovery Vehicle (RRV) – 50485

✔
You can view the items you want quotes on by clicking View Selected Items above.

Warthog Armoured All Terrain Repair Recovery Vehicle (RRV)

Item Ref

Ref: 50485
Category Armoured Fighting Vehicles (AFV's)
Manufacturer ST Kinetics
Quantity 0
Hours / Mileage
This item is sold
About This Item
Warthog Armoured All Terrain Repair Recovery Vehicle (RRV)

The Repair Recovery Variant (RRV) is to serve as a mobile heavy aid workshop to facilitate repairs and maintenance in the field. The RRV consists of a typical front cabin configuration and a flat bed rear cabin.

Onboard equipment on the flatbed consists of a Palfinger 6mT crane mounted on a subframe. The RRV is also equipped with a constant pull winch which is capable of providing a maximum 10T pulling force. The subframe carries a pair of anchor spades which help to support the vehicle during lifting or winching operations. A 23 CFM air compressor with 2 hose reels is also provided to allow power tools to be used. Finally a workbench and vice unit and storage units are carried to facilitate maintenance tasks to be carried out.

In addition a Hatz engine is included to provide both electrical power and hydraulic power to various subsystems.

Body design - Front and rear module, high strength steel with protection system

Performance:

  • Cruising Range - 400 Km
  • Maximum road speed - 60 Km/hr
  • Fuel consumption - 1.10 litres/km
  • Maximum gradient - 60%
  • Maximum side slope - 30%
  • Maximum vertical obstacle - 0.8M
  • Trench - 1.5M
  • Steering Radius - 10M
  • Front towing attachment ( max towing load) 30 Tonnes
  • Rear towing pintle (max towing load) 30 Tonnes
  • Maximum fording depth 1.5M
  • Engine Type - Caterpillar C7 350 BHP, 6 cylinder, 4 stroke turbo charged
  • Transmission Type - Allison MD3500 fully Automatic 6 speed
  • Cooling system - Liquid and air cooled

    • Air conditioning is provided for the front module

    A heating system is provided in the front and rear module designed to provide heating between 10-40 degrees

    We also have available in stock the Troop carrier variant, Command variant and Ambulance Variant totalling 75 vehicles as well as a full spares package

    Specifications
    Category Armoured Fighting Vehicles (AFV's)
    Manufacturer ST Kinetics
    Engine Caterpillar C7 350 BHP 6 Cylinder Turbo Charged
    Gearbox Allison MD3500 fully automatic 6 speed
    Brakes
    Steering Centre Point Articulation
    Maximum Load
    Electrics 24 volts
    Length × Width × Height L: 8.60M × W: 2.30m × H: 2.90m
    Gross Weight
    Date into Service 2010-2011
    Year of Manufacture 2010-2011
    Hours / Mileage
    Quantity Available 0
    Export Requirements SIEL Licence Required
    Condition Report

    We offer vehicles in the following conditions:

    • As received from the relevant MoD with a workshop check to make sure it runs and drives, but with no reparatory works. (AS IS)
    • Fully prepared, including servicing of all major components and a fresh coat of paint. (PREPARED)
